Fiberglass Mesh In Plain Weave E Glass Fiberglass Woven Roving 400g 600g 800g

100 Square Meter
MOQ
US $0.15 - 0.35/ Square Meter
Price
Fiberglass Mesh In Plain Weave E Glass Fiberglass Woven Roving 400g 600g 800g
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Fiberglass Mesh
Key Words: Fiberglass Mesh In Plain Weave E Glass Fiberglass Woven Roving 400g 600g 800g
Material: Fiberglass Yarn
Size: Can Be Custom Made
Weigth: 75g, 90g, 110g, 125g, 145g, 160g, Etc
Mesh Size: 5x5mm, 4x4mm, 3x3mm
Hs Code: 7019590000
Use: Wall Material
Highlight:

Plain Fiberglass Mesh

,

400g Fiberglass Mesh

,

600g Fiberglass Mesh

Basic Infomation
Place of Origin: CHINA
Brand Name: YUDA
Model Number: Glass fibre mesh
Payment & Shipping Terms
Packaging Details: Customized according to buyer's requirements
Delivery Time: 3-10 day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 rolls/ day
Product Description

Fiberglass Mesh In Plain Weave E Glass Fiberglass Woven Roving 400g 600g 800g





Item Number
Yarn(Tex)
Mesh size(mm)
Density Count/25mm
Finished weight(g/m2)
Tensile StrengthX20cm
Warp
Weft
Warp
Weft
Warp
Weft
Warp
Weft
NQ 5X5-70
45X2
200
5
5
5
5
70
550
850
NQ 5X5-80
67X2
200
5
5
5
5
80
700
850
NQ 5X5-90
67X2
250
5
5
5
5
90
700
1050
NQ 5X5-110
100X2
250
5
5
5
5
110
800
1050
NQ 5X5-125
134X2
250
5
5
5
5
125
1200
1300
NQ 5X5-135
134X2
300
5
5
5
5
135
1300
1400
NQ 4X4-135
100X2
250
4
4
6
6
135
1000
1300
NQ 5X5-145
134X2
360
5
5
5
5
145
1200
1300
NQ 4X5-150
134X2
300
4
5
6
5
150
1300
1300
NQ 5X5-160
134X2
400
5
5
5
5
160
1450
1600
NQ 4X4-160
134X2
300
4
4
6
6
160
1550
1650
NQ 4X5-165
134X2
350
4
5
6
5
165
1300
1300



Fiberglass Mesh In Plain Weave E Glass Fiberglass Woven Roving 400g 600g 800g 0



Main characteristics :



1.Good chemical stability: Alkali-resistant, acid-resistant, waterproof,, cement erosion-resistant, and
other chemicals' corrosion resistant; and strong resin bonding, soluble in styrene.
2.Good dimensional stability, stiffness, smoothness an difficult to shrink and deformation, good positioning property..
3.Good impact resistance and not easy to be teared.
4.Fire resistant, thermal insulation, sound insulation, insulations etc.

Fiberglass Mesh In Plain Weave E Glass Fiberglass Woven Roving 400g 600g 800g 1

1. 75g / m2 mesh fabric used in the reinforcement of thin slurry, to eliminate small cracks and

scattered throughout the surface pressure.
2. 110g / m2 mesh cloth is widely used in indoor and outdoor walls, prevent the various materials

(such as brick, light wood, prefabricated structure) of treatment or caused by a variety of expansion

coefficient of wall crack and break .
3. 145g/m2 mesh fabric used in the wall and be mixed in various materials (such as brick, light

wood, prefabricated structures), to prevent cracking and scatter the whole surface pressure,

especially in the external wall insulation system (EIFS ).
4. 160g / m2 mesh fabric used in insulator layer of reinforcement in the mortar, through

shrinkage and temperature changes by providing a space to maintain movement between the

layers, prevent crack and rupture due to shrinkage or temperature change.



Fiberglass Mesh In Plain Weave E Glass Fiberglass Woven Roving 400g 600g 800g 2



Fiberglass mesh cloth is commonly used in architecture, decoration and engineering, and its main uses include:

Wall reinforcement: Glass fiber mesh cloth can be applied to building walls to increase the crack resistance and impact resistance of the wall and prevent wall cracking.
Fire isolation: Because the glass fiber has high temperature resistance, it can be used to make fire isolation curtains and fire partitions to provide fire safety protection.
Floor reinforcement: During the floor laying stage, fiberglass mesh cloth can be used in combination with cement or other floor materials to enhance the bearing capacity and crack resistance of the floor.
Tile back reinforcement: During the tile laying process, glass fiber mesh cloth can be used to reinforce the back of the tile to prevent the tile from cracking and falling off.
Protection and filtration: Fiberglass mesh cloth can be used for protection and filtration applications, such as window bug nets, air conditioning filters, etc.
