Roving Fiberglass Cloth 5*5mm Excellent Tensile Strength Fiberglass Products

100 Square Meter
MOQ
US $0.15 - 0.35/ Square Meter
Price
Roving Fiberglass Cloth 5*5mm Excellent Tensile Strength Fiberglass Products
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Fiberglass Mesh
Key Words: Roving Fiberglass Cloth Fiberglass Mesh Excellent Tensile Strength Fiberglass Products
Material: Fiberglass Yarn
Apertue: 4*4mm,5*5mm Etc.
Coating: Emulsion Coated, Urea Glue Coated
Materials: C-glass
Tensile Strength: 75N/5cm, 100N/5cm, 150N/5cm, 200N/5cm
Hole Shape: Square
Usage: Building Wall
Highlight:

5*5mm Fiberglass Cloth

,

Tensile Strength Fiberglass Cloth

,

5*5mm fiberglass cloth roll

Basic Infomation
Place of Origin: CHINA
Brand Name: YUDA
Certification: IOS
Model Number: Glass fibre mesh
Payment & Shipping Terms
Packaging Details: Customized according to buyer's requirements
Delivery Time: 3-10 day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 rolls/ day
Product Description

Roving Fiberglass Cloth Fiberglass Mesh Excellent Tensile Strength Fiberglass Products





Glass fiber mesh,fiberglass plaster net,fiberglass mesh netting
SPECIFICATION
Material:
Fiberglass Yarn
Coating: Latex, Urine Glue
Weight (grams/sq m): 60g - 300g/m²
Length: 10m-300m
Width: 4.5cm-2m
Color: White(standard),red, yellow, blue, green, gray, black or other colors
Mesh Size
Density(grams/sqm)
Width(m)
Length per roll(m)
4 x 5
160

4.5cm-2m

10-300m
5 x 5
80,100,125,145
6 x 6
240,300
Other specifications , accept customization





Roving Fiberglass Cloth 5*5mm Excellent Tensile Strength Fiberglass Products 0



Reinforced Fiberglass Wall Mesh Specification:
Item Number Yarn(Tex) Mesh(mm) Density Count/25mm Tensile Strength × 20cm Woven Structure Content of resin%
Warp Weft Warp Weft Warp Weft Warp Weft
45g2.5x2.5 33×2 33 2.5 2.5 10 10 550 300 Leno 18
60g2.5x2.5 40×2 40 2.5 2.5 10 10 550 650 Leno 18
70g 5x5 45×2 200 5 5 5 5 550 850 Leno 18
80g 5x5 67×2 200 5 5 5 5 700 850 Leno 18
90g 5x5 67×2 250 5 5 5 5 700 1050 Leno 18
110g 5x5 100×2 250 5 5 5 5 800 1050 Leno 18
125g 5x5 134×2 250 5 5 5 5 1200 1300 Leno 18
135g 5x5 134×2 300 5 5 5 5 1300 1400 Leno 18
145g 5x5 134×2 360 5 5 5 5 1200 1300 Leno 18
150g 4x5 134×2 300 4 5 6 5 1300 1300 Leno 18
160g 5x5 134×2 400 5 5 5 5 1450 1600 Leno 18
160g 4x4 134×2 300 4 4 6 6 1550 1650 Leno 18
165g 4x5 134×2 350 4 5 6 5 1300 1300 Leno

18













































Feature
1. It is single coated with organic silicone adhesive and laminated with double sided

anti-static protective film.
2. Using blue PET film as carrier.
3. It has the function of low adhesion and anti-static.

Roving Fiberglass Cloth 5*5mm Excellent Tensile Strength Fiberglass Products 1



1. 75g / m2 mesh fabric used in the reinforcement of thin slurry, to eliminate small cracks and



scattered throughout the surface pressure.
2. 110g / m2 mesh cloth is widely used in indoor and outdoor walls, prevent the various materials

(such as brick, light wood, prefabricated structure) of treatment or caused by a variety of expansion

coefficient of wall crack and break .
3. 145g/m2 mesh fabric used in the wall and be mixed in various materials (such as brick, light

wood, prefabricated structures), to prevent cracking and scatter the whole surface pressure,

especially in the external wall insulation system (EIFS ).
4. 160g / m2 mesh fabric used in insulator layer of reinforcement in the mortar, through

shrinkage and temperature changes by providing a space to maintain movement between the

layers, prevent crack and rupture due to shrinkage or temperature change.





Roving Fiberglass Cloth 5*5mm Excellent Tensile Strength Fiberglass Products 2
