Name: Fiberglass Reinforcing Mesh Epoxy Resin Fiberglass Eifs Mesh
Brand: Anping Yuda Wire Mesh Co., Ltd.
SKU: Glass fibre mesh
Price: 0.15 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Product Name: Fiberglass Mesh

Key Words: Reinforced Fiberglass Mesh Netting For Concrete Fiberglass Mesh Plaster Net

Material: Fiberglass Yarn

Size: Can Be Custom Made

Colors: White,Yellow ,blue

Apertue: 4*4mm,5*5mm Etc.

Coating: Emulsion Coated, Urea Glue Coated

Highlight:

Epoxy Resin Fiberglass Mesh

Eifs Fiberglass Mesh

Fiberglass Reinforcing Mesh

Basic Infomation

Place of Origin: CHINA

Brand Name: YUDA

Certification: IOS

Model Number: Glass fibre mesh

Document: Product Brochure PDF

Payment & Shipping Terms

Packaging Details: Customized according to buyer's requirements

Delivery Time: 3-10 day

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 5000 rolls/ day

Gallery

Fiberglass Reinforcing Mesh Epoxy Resin Fiberglass Eifs Mesh

Product Description

Fiberglass Reinforcing Mesh Epoxy Resin Fiberglass Eifs Mesh

Fiberglass woven roving fabric is a mesh material made of woven glass fibers with a chevron-like fiber structure. It is usually made of glass fiber as raw material through the weaving process.E-Glass Woven Rovings are bidirectional fabric made by interweaving direct rovings.

E-Glass Woven Rovings are compatible with unsaturated polyester, vinyl ester, epoxy and phenolic resins.

E-Glass Woven Rovings are a high-performance reinforcement widely used in hand lay up and robot processes to manufacture boats, vessels, plane and automotive parts, furniture and sports facilities.

Glass fiber mesh fabric, as a high-performance composite material, is mainly woven from high-strength glass fiber filaments, and its surface is often coated with resin coatings that are alkali resistant or waterproof. This material has been widely used in multiple industrial fields due to its unique physical and chemical properties. Fiberglass mesh fabric not only has excellent tensile strength and deformation resistance, but also has good corrosion resistance and weather resistance, making it an indispensable and important material in modern construction, transportation, shipbuilding, and environmental engineering fields.

Wall reinforcement: As a reinforcement layer of the wall insulation system, it improves the overall strength and stability of the wall.
External wall insulation: Used in combination with insulation materials to effectively prevent cracking and enhance insulation effectiveness.
Roof waterproofing: As a reinforcement material for the waterproof layer, it improves the durability and crack resistance of the waterproof layer.

Reinforced Fiberglass Wall Mesh Specification:

Item Number	Yarn(Tex)		Mesh(mm)		Density Count/25mm		Tensile Strength × 20cm		Woven Structure	Content of resin%
Item Number	Warp	Weft	Warp	Weft	Warp	Weft	Warp	Weft
45g2.5x2.5	33×2	33	2.5	2.5	10	10	550	300	Leno	18
60g2.5x2.5	40×2	40	2.5	2.5	10	10	550	650	Leno	18
70g 5x5	45×2	200	5	5	5	5	550	850	Leno	18
80g 5x5	67×2	200	5	5	5	5	700	850	Leno	18
90g 5x5	67×2	250	5	5	5	5	700	1050	Leno	18
110g 5x5	100×2	250	5	5	5	5	800	1050	Leno	18
125g 5x5	134×2	250	5	5	5	5	1200	1300	Leno	18
135g 5x5	134×2	300	5	5	5	5	1300	1400	Leno	18
145g 5x5	134×2	360	5	5	5	5	1200	1300	Leno	18
150g 4x5	134×2	300	4	5	6	5	1300	1300	Leno	18
160g 5x5	134×2	400	5	5	5	5	1450	1600	Leno	18
160g 4x4	134×2	300	4	4	6	6	1550	1650	Leno	18
165g 4x5	134×2	350	4	5	6	5	1300	1300	Leno	18

Prouduct Application
1. On-site construction and pre-mixing method to make exterior wall panels, permanent formwork, wall mortar covering.
2. Prefabricated bridge beams, building support columns, Roman columns to prevent surface cracking.
3. Production of GRC architectural details, GRC exterior wall hanging panels, GRC garden landscape products, GRC lightweight partition panels, GRC insulation panels, ventilation ducts, permanent tubular mandrels, permanent formwork,industrial building roofing components, sound barriers, Self-supporting floors, irrigation channels, etc.

Company Profile

Anping County Yuda Wire Mesh Products Co., Ltd. Is Located In "anping County, Hebei Province", A Famous Wire Mesh Hometown In The Country. It Specializes In The Production Of Fiberglass Mesh Cloth, Insulation Nails, Welded Wire Mesh, Dutch Wire Mesh And Other Products. Production Experience, As Well As Advanced Assembly Lines And Mechanical Equipment.

The Company Mainly Produces: Dipped Dutch Nets, Wave-shaped Fence Nets, Wave-shaped Dutch Nets, Wave Nets, Dutch Net Fences, Pvc-coated Dutch Nets, Plastic-coated Welded Nets, Hot And Cold Galvanized Welded Nets, Meshes And Other Products.
