Home /Products/Field Fence/Fixed Knot Woven Wire Field Fence Galvanized Sheep Farm Fence

Fixed Knot Woven Wire Field Fence Galvanized Sheep Farm Fence

10 roll
MOQ
Decided based on requirements
Price
Fixed Knot Woven Wire Field Fence Galvanized Sheep Farm Fence
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Field Fence
Key Words: High Tensile Strength
Material: Low-Carbon Iron Wire
Application: Fence Mesh,grassland,sheep
Height: 0.8-2.0m Or As Your Demand
Length: 50m 100m Or As Your Request
Usage: Protecting Wire Mesh Fence
Diameter: CUSTOMIZED
Highlight:

Knot Woven Wire Field Fence

,

Fixed Knot Woven Wire Field Fence

,

Galvanized Sheep Farm Fence
Basic Infomation
Place of Origin: CHINA
Brand Name: YUDA
Model Number: Field fence
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Customized according to buyer's requirements
Delivery Time: 3-10 day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 roll/ day
Product Description

Fixed Knot Woven Wire Field Fence Galvanized Sheep Farm Fence​



The livestock wire fence made by mild steel wire and high tensile steel wire. Now factory mainly offers two type: hinge joint knots and fix knots .

The hinge joint knots is the most common knot in agricultural fencing. The knot is formed by wrapping the vertical stay wire pieces around the line wire at each intersection. This design can also absolve animal impact without damage and is the most economical knot choice available.

Fixed knot field fence considered top-of-the-line as the fixed knot utilizes a separate piece of wire tightly wrapped around the line wire and stay wire, increasing the fence’s vertical strength allowing for increased post spacing and making it very resistant to animal damage.

Hinge Joint Knots and Fixed Knots Fence Specification
Height Range: 0.6 to 2.5 meter available.
Vertical wire distance : 50, 100,150,200,250,300,350,400mm available
Length : 50 Meter , 100 Meter and 150 Meter available .
Wire Material Finishing: Hot Dipped Galvanized, Electro Galvanized.

On the basis of the ordinary Field fence, an advanced pressure wave process is adopted, and one or two deep 12 mm wide and 40 mm bends are pressed on each mesh of the horizontal wire.T his kind of technology makes the mesh surface flatter and effectively enhances the elasticity of the mesh surface. It alleviates the deformation of the mesh surface caused by thermal expansion and contraction in areas with large climate change in winter and summer. Since the ripple increases the cushioning force of the mesh surface, the mesh surface can automatically return when the beast hits.



Style specification
weight
kg
Edge
wire mm
Inner
wire mm
7/150/813/50
102+114+127+140+152+178
19.3
2.5
2.0
8/150/813/50
89(75)+89+102+114+127+140+152
20.8
2.5
2.0
8/150/902/50
89+102+114+127+140+152+178
21.6
2.5
2.0
8/150/1016/50
102+114+127+140+152+178+203
22.6
2.5
2.0
8/150/1143/50
114+127+140+152+178+203+229
23.6
2.5
2.0
9/150/991/50
89(75)+89+102+114+127+140+152+178
23.9
2.5
2.0
10/150/1245/50
102+114+127+140+152+178+203+229
26.0
2.5
2.0
10/150/1194/50
89(75)+89+102+114+127+140+152+178+203+229
27.3
2.5
2.0
19/150/1442/50
89+102+114+127+140+152+178+203+229
28.4
2.5
2.0
11/150/1442/50
89(75)+89+102+114+127+140+152+178+203+229
30.8
2.5
2.0





Fixed Knot Woven Wire Field Fence Galvanized Sheep Farm Fence 0Fixed Knot Woven Wire Field Fence Galvanized Sheep Farm Fence 1Fixed Knot Woven Wire Field Fence Galvanized Sheep Farm Fence 2
