Home /Products/Crimped Wire Mesh/High Temperature Metal Crimped Wire Mesh Square Hole Screen Net

High Temperature Metal Crimped Wire Mesh Square Hole Screen Net

100 Square Meter
MOQ
Determine based on size and quantity
Price
High Temperature Metal Crimped Wire Mesh Square Hole Screen Net
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Crimped Wire Mesh
Key Words: Crimped Mesh
Technique: Woven
Wire Diameter: Requirement
Hole Shape: Square Hole,as Per Requirement
Width: Customized
Surface: Galvanised / Stainless Steel / PVC
Application: Mining,coal Factory,rail Road,farm,BBQ
Highlight:

Square Hole Crimped Wire Mesh

,

High Temperature Crimped Wire Mesh

,

Metal Crimped Wire Mesh
Basic Infomation
Place of Origin: CHINA
Brand Name: YUDA
Model Number: crimped wire mesh
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Customized according to buyer's requirements
Delivery Time: 3-10 day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200000 Square Meter/ day
Product Description

High Temperature Metal Crimped Wire Mesh Square Hole Screen Net



Flat Top Wire Mesh
Flat top wire mesh is manufactured with wires crimped on one side only to create a flat surface, thus enhancing its durability and allowing bigger apertures with high precision. It is generally used for coarse mineral screening.

Lock Crimp Wire Mesh
Before weaving, both warp and weft wires are pre-crimped. Lock Crimp Wire Mesh is characterized by the formation of bumps or joints on each group of intersecting wires. These joints lock the mesh in place and create an extremely rigid product.

Double Crimp Wire Mesh
Double crimp wire mesh is manufactured with pre-crimped wires to obtain precise screening apertures and achieve maximum rigidity.
Generally, it works well in conditions where materials are not sticky or materials with a small tendency to peg or wedge.

High quality raw materials
high strength, high stiffness and high load-bearing capacity.

High quality features
wear resistant and corrosion-resistant, with long service life.

Own R&D factory, support custom
wire diameter, aperture, size, color, and whether it is bent, etc. All above support customization.

Packing&shipping
We support multiple packaging methods for vibrating screen mesh:
1. in bundle
2. on tray
3. plastic film+wooden tray
4. plastic film+metal tray
Shipping methods: land transportation, sea transportation, air transportation and other forms.
We will also choose the most suitable logistics method for you based on your purchase quantity and packaging size.


CHEMICAL COMPOSITION

Material C≤ Mn≤ Si≤ S≤ P≤ Cr≤ Ni Mo N
S31803(SAF2205) 0.03 2 1 0.02 0.03 21.0/23.0 4.50/6.50 2.50/3.50 0.08/0.20
00Cr22Ni5Mo3N
PHYSICAL PROPERTIES
Material σb(Mpa)≥ σs(Mpa)≥ δ(%)≥ Hardness (stiffness)
(HB) (HRC)
S31803(SAF2205) 620 450 25 290 30.5
00Cr22Ni5Mo3N



High Temperature Metal Crimped Wire Mesh Square Hole Screen Net 0High Temperature Metal Crimped Wire Mesh Square Hole Screen Net 1
