Home /Products/Road Noise Barrier/Steel Panel Sound Barrier for Highway and Railway Noise Reduction

Steel Panel Sound Barrier for Highway and Railway Noise Reduction

50 Piece
MOQ
Determined by size and quantity
Price
Steel Panel Sound Barrier for Highway and Railway Noise Reduction
Features Gallery Product Description Chat Now
Features
Specifications
Product Name: Sound Barrier
Key Words: Outdoor Sound Barrier
Panel Style: Steel Panel, PC Board
Application: Highway,Railway,Noise Barrier,etc
Panel Thickness: At Your Requst
Panel Length: 2m~4m Can Custom
Feature: High Stability, Eco-friendly, Effective Railway Noise Barrier
Sheets Thickness: 0.8-1mm, Can Be Customized
Highlight:

Road Noise Barrier Sheet

,

Highway Soundproof Panel

,

Sound Barrier Road Noise Barrier Sheet
Basic Infomation
Place of Origin: CHINA
Brand Name: YUDA
Model Number: Sound barrier
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Customized according to buyer's requirements
Delivery Time: 3-10 day
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 200000 Meters/ day
Product Description
Sound Barrier Road Noise Barrier Sheet Highway Soundproof Panel
Product Overview

A noise barrier (also called soundwall, sound berm, or acoustical barrier) is an exterior structure designed to protect sensitive areas from noise pollution. Our sound barriers effectively reduce noise through advanced engineering and quality materials.

Key Features
  • Available in steel panel or PC board construction
  • High stability and eco-friendly design
  • Effective noise reduction for highways and railways
  • Customizable thickness and dimensions
  • Durable construction withstands outdoor conditions
Specifications
Attribute Value
Panel Style Steel panel, PC board
Application Highway, Railway, Noise Barrier
Panel Thickness Customizable
Panel Length 2m~4m (customizable)
Sheets Thickness 0.8-1mm (customizable)
Technical Details

Standard heights available: 2,000mm, 2,500mm, 3,000mm with pole spacing of 1,000mm, 2,000mm or 2,500mm. The steel structure and sound insulation screen are designed to withstand expressway and subway wind loads, traffic impact, and outdoor weather conditions.

Components
Component Description
Noise Barrier Panel Galvanized sheet, aluminum alloy, color plate, glass, PC board, acrylic board, high strength cement, cement wood chips, fiberglass
Hole Pattern Louver holes (20*137, 20*182) or micropores (3 holes 3 distances, 5 holes 2 distances, 2 holes 4 distances)
H Shape Post Material: Q235B, Common sizes: 100*100*6*8 to 175*175*735*11, Height: 2m-6m (up to 12m)
Noise Absorb Material Glass wool, rock wool, water-repellent cloth, acoustic felt, foam aluminum fiber
Applications

Primarily used for sound insulation and noise reduction in transportation and municipal facilities including expressways, elevated roads, urban light rail, and subways. Also effective for industrial noise control in factories and other noise sources.

Frequently Asked Questions
Q: Are you a factory or trading company?
A: We are a factory.
Q: What certificate do you have?
A: We have ISO and CE certificate.
Q: How does your factory do regarding quality control?
A: We have a special QC department in charge of products' quality.
Q: How long is the warranty period?
A: All of our products have one year warranty.
Q: What's the main market of your company?
A: We have customers all over the world.
Steel Panel Sound Barrier for Highway and Railway Noise Reduction 0 Steel Panel Sound Barrier for Highway and Railway Noise Reduction 1 Steel Panel Sound Barrier for Highway and Railway Noise Reduction 2
